Troubleshooting

Examples of False-Alarm Occurrence from system characteristics (It’s not a problem)

–	Characteristics of EM Wave : EM Waves are reflected against all material and especially metal very well. Reflections of EM Waves are varies with the shape of object. (? EM : Electro Magnetic)

–	Radar Sensor : Radar Sensor sense the car by 24GHz echo signal.

–	Special enviroment make the ''False-Alarm'' occurrence because of EM waves.

Blind Spot Detection Indicator Repair procedures

Removal 1. Disconnect the negative (-) battery terminal. 2. Remove the mirror (C) from the mirror holder after disconnecting the heater connector (A) and BSD warning connector (B). 3. Remove the BSD warning ...
